3P/24V(25A) Socket (without standard)
Article Number151296
Show downloads
Downloads
Product information
| Name | 3P/24V(25A) Socket (without standard) |
|---|---|
| Article Number | 151296 |
| Categories | Socket |
| Standards | without standard |
| Industries | Agriculture , Commercial vehicles |
| Rated current / permanent load [in A] | 25 |
|---|---|
| Voltage [in V] | 24 |
| Packaging | retail bag |
|---|
| Type of seal | sealing plug |
|---|
| Contact insert color | black |
|---|---|
| Contact surface | silver (Ag) |
| Housing color | silver-colored |
| Housing material | break-proof metal |
| Cable outlet | cap nut |
|---|---|
| Contact termination | screw contact |
| Contact version | contact pin |
| No. of poles | 03 |
| Contact: for max. wire cross section [in mm²] | 6,00 |
|---|---|
| For cable diameter | 11,40mm - 14,00mm |
